Specifications Si39-302
34 Specifications
Wall Mounted Type
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m,
level difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length:7.5m,
level difference: 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m,
level difference; 0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
5 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of installation conditions.
Model FXAQ20MVE FXAQ25MVE FXAQ32MVE
★
★★
★
1 Cooling Capacity (19.5°CWB)
kcal/h 2,000 2,500 3,150
Btu/h 7,900 9,900 12,500
kW 2.3 2.9 3.7
★
★★
★
2 Cooling Capacity (19.0°CWB) kW 2.2 2.8 3.6
★
★★
★
3 Heating Capacity
kcal/h 2,200 2,800 3,400
Btu/h 8,500 10,900 13,600
kW 2.5 3.2 4.0
Casing Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 290×795×230 290×795×230 290×795×230
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×14×1.4 2×14×1.4 2×14×1.4
Face Area m² 0.161 0.161 0.161
Fan
Model — — —
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output × Number
of Units
W 40×1 40×1 40×1
Air Flow Rate (H/L)
m³/min 7.5/4.5 8/5 9/5.5
cfm 265/159 282/177 318/194
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material
Foamed Polystyrene /
Foamed Polyethylene
Foamed Polystyrene /
Foamed Polyethylene
Foamed Polystyrene /
Foamed Polyethylene
Air Filter Resin Net (Washable) Resin Net (Washable) Resin Net (Washable)
Piping
Connections
Liquid Pipes mm
φ
6.4 (Flare Connection)
φ
6.4 (Flare Connection)
φ
6.4 (Flare Connection)
Gas Pipes mm
φ
12.7 (Flare Connection)
φ
12.7 (Flare Connection)
φ
12.7 (Flare Connection)
Drain Pipe mm
VP13
(External Dia. 18 Internal Dia. 13)
VP13
(External Dia. 18 Internal Dia. 13)
VP13
(External Dia. 18 Internal Dia. 13)
Machine Weight kg 11 11 11
★
★★
★
5 Sound Level (H/L) dBA 35/29 36/29 37/29
Safety Devices Fuse Fuse Fuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R410A M Series R410A M Series R410A M Series
Standard Accessories
Operation Manual, Installation
Manual, Installation Panel, Paper
Pattern for Installation, Insulation
Tape, Clamps, screws.
Operation Manual, Installation
Manual, Installation Panel, Paper
Pattern for Installation, Insulation
Tape, Clamps, screws.
Operation Manual, Installation
Manual, Installation Panel, Paper
Pattern for Installation, Insulation
Tape, Clamps, screws.
Drawing No.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
