Si39-302 Specifications
Specifications 35
Wall Mounted Type
Notes: ★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp; 35°CDB / Equivalent piping length: 7.5m,
level difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp; 35°CDB / Equivalent piping length: 7.5m,
level difference: 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m,
level difference; 0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
5 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of installation conditions.
Model FXAQ40MVE FXAQ50MVE FXAQ63MVE
★
★★
★
1 Cooling Capacity (19.5°CWB)
kcal/h 4,000 5,000 6,300
Btu/h 15,900 19,900 25,000
kW 4.7 5.8 7.3
★
★★
★
2 Cooling Capacity (19.0°CWB) kW 4.5 5.6 7.1
★
★★
★
3 Heating Capacity
kcal/h 4,300 5,400 6,900
Btu/h 17,000 21,500 27,300
kW 5.0 6.3 8.0
Casing Color White (B-272) White (B-272) White (B-272)
Dimensions: (H×W×D) mm 290×1,050×230 290×1,050×230 290×1,050×230
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×14×1.4 2×14×1.4 2×14×1.4
Face Area m² 0.161 0.161 0.161
Fan
Model — — —
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output × Number
of Units
W 43×1 43×1 43×1
Air Flow Rate (H/L)
m³/min 12/9 15/12 19/14
cfm 424/318 530/424 671/494
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material
Foamed Polystyrene /
Foamed Polyethylene
Foamed Polystyrene /
Foamed Polyethylene
Foamed Polystyrene /
Foamed Polyethylene
Air Filter Resin Net (Washable) Resin Net (Washable) Resin Net (Washable)
Piping
Connections
Liquid Pipes mm
φ
6.4 (Flare Connection)
φ
6.4 (Flare Connection)
φ
9.5 (Flare Connection)
Gas Pipes mm
φ
12.7 (Flare Connection)
φ
12.7 (Flare Connection)
φ
15.9 (Flare Connection)
Drain Pipe mm VP13 VP13 VP13
Machine Weight kg 14 14 14
★
★★
★
5 Sound Level (H/L) dBA 39/34 42/36 46/39
Safety Devices Fuse Fuse Fuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R410A M Series R410A M Series R410A M Series
Standard Accessories
Operation Manual, Installation
Manual, Installation Panel, Paper
Pattern for Installation, Insulation
Tape, Clamps, screws.
Operation Manual, Installation
Manual, Installation Panel, Paper
Pattern for Installation, Insulation
Tape, Clamps, screws.
Operation Manual, Installation
Manual, Installation Panel, Paper
Pattern for Installation, Insulation
Tape, Clamps, screws.
Drawing No.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
