List of Electrical and Functional Parts Si39-302
268 Appendix
Parts Name
Symbol
Model
Remark
FXHQ
32MVE
FXHQ
63MVE
FXHQ
100MVE
Remote
Controller
Wired Remote
Controller
BRC1A61 Option
Wireless Controller BRC7E63W
Motors
Fan Motor M1F
AC 220~240V/220V 50Hz/60Hz
1
φ
63W 1
φ
130W
Thermal protector 130°C : OFF 80°C : ON
Capacitor for Fan Motor
C1R 3.0
µ
F-400V
9.0µF-400V
Swing Motor M1S
MT8-L[3P058751-1]
AC200~240V
Thermistors
Thermistor (Suction Air) R1T
ST8601A-1
φ
4 L250
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-6
φ
8 L = 1250
20k
Ω
(25°C)
ST8605-6 φ8 L
= 1250
20kΩ (25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-6
φ
6 L = 1250
20k
Ω
(25°C)
ST8602A-6 φ6 L
= 1250
20kΩ (25°C)
Others
Fuse F1U 250V 5A
φ
5.2
Transformer T1R TR22H21R8
Parts Name
Symbol
Model
Remark
FXAQ
20MVE
FXAQ
25MVE
FXAQ
32MVE
FXAQ
40MVE
FXAQ
50MVE
FXAQ
63MVE
Remote
Controller
Wired Remote
Controller
BRC1A61 Option
Wireless Remote
Controller
BRC7E618 Option
Motors
Fan Motor M1F
AC 220~240V 50Hz
1
φ
40W 1
φ
43W
Thermal protector 130°C : OFF 80°C : ON
Swing Motor M1S
MP24[3SB40333-1]
AC200~240V
MSFBC20C21 [3SB40550-1]
AC200~240V
Thermistors
Thermistor (Suction Air) R1T
ST8601-2
φ
4 L400
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-2
φ
8 L400
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger)
R2T
ST8602-2
φ
6 L400
20k
Ω
(25°C)
Others
Float Switch S1L
OPTION
Fuse F1U 250V 5A
φ
5.2
