Special Control Si39-302
82 Function
3.7 Pressure Equalization prior to Startup
Actuator Operation Remarks
Compressor OFF
Outdoor unit fan
Cooling:OFF
Heating:STEP 4
Four way valve Holds ON
Main motorized valve (EV1) 0 pls
Subcooling motorized valve (EV2) 0 pls
Hot gas bypass valve (SVP) OFF In the case of RXYQ5M, this valve turns ON.
Oil equalization valve (SVO) OFF
Receiver gas charging valve (SVL) OFF
Receiver gas discharging valve
(SVG)
OFF
Non-operating unit gas discharging
valve (SVSG)
OFF
Non-operating unit liquid pipe stop
valve (SVSL)
OFF
Ending conditions 10 sec.
In the case of RXYQ5M, 3 min. or Pc
-
Pe<0.2
MPa
