Si39-302 Specifications
Specifications 15
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m,
level difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m,
level difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m,
level difference : 0m.
Model Name (Combination Unit) RXYQ26MY1B RXYQ28MY1B
Model Name (Independent Unit) RXYQ10MY1B+RXYQ16MY1B RXYQ12MY1B+RXYQ16MY1B
★
1 Cooling Capacity (19.5°CWB)
kcal / h 65,000 70,000
Btu / h 256,000 275,000
kW 74.9 80.5
★
2 Cooling Capacity (19.0°CWB) kW 72.5 78.0
★
3 Heating Capacity
kcal / h 70,000 75,300
Btu / h 279,000 299,000
kW 81.5 87.5
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm (1600×930×765)+(1600×1240×765) (1600×1240×765)+(1600×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Displacement m³/h (13.72+10.47)+(13.72+10.47+10.47) (13.72+10.47)+(13.72+10.47+10.47)
Number of Revolutions r.p.m (6480, 2900)+(6480, 2900×2) (6480, 2900)+(6480, 2900×2)
Motor Output×Number
of Units
kW (2.7+4.5)+(3.0+4.5+4.5) (4.2+4.5)+(3.0+4.5+4.5)
Starting Method Soft start Soft start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×2 0.75×2
Air Flow Rate m³/min 180+210 210+210
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
19.1 (Brazing Connection)
φ
19.1 (Brazing Connection)
Gas Pipe mm
φ
34.9 (Brazing Connection)
φ
34.9 (Brazing Connection)
Oil Equalizing Pipe mm
φ
6.4 (Flare Connection)
φ
6.4 (Flare Connection)
Machine Weight kg 230+325 281+325
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 6~100 6~100
Refrigerant
Refrigerant Name R410A R410A
Charge kg 9.6+14.4 11.4+14.4
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator
Oil
Synthetic (ether) oil Synthetic (ether) oil
Charge Volume L (1.9+1.6)+(1.9+1.6+1.6) (1.9+1.6)+(1.9+1.6+1.6)
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. 4D038966A, 4D038969A 4D038967A, 4D038969A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
