Si39-302 Specifications
Specifications 33
Ceiling Suspended Type
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m,
level difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m,
level difference: 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m,
level difference; 0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
5 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of installation conditions.
Model FXHQ32MVE FXHQ63MVE FXHQ100MVE
★
★★
★
1 Cooling Capacity (19.5°CWB)
kcal/h 3,150 6,300 10,000
Btu/h 12,500 25,000 39,700
kW 3.7 7.3 11.6
★
★★
★
2 Cooling Capacity (19.0°CWB) kW 3.6 7.1 11.2
★
★★
★
3 Heating Capacity
kcal/h 3,400 6,900 10,800
Btu/h 13,600 27,300 42,700
kW 4.0 8.0 12.5
Casing Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 195×960×680 195×1,160×680 195×1,400×680
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×12×1.75 3×12×1.75 3×12×1.75
Face Area m² 0.182 0.233 0.293
Fan
Model 3D12K1AA1 4D12K1AA1 3D12K2AA1
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 62×1 62×1 130×1
Air Flow Rate (H/L)
m³/min 12/10 17.5/14 25/19.5
cfm 424/353 618/494 883/688
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Wool Glass Wool Glass Wool
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Piping
Connections
Liquid Pipes mm
φ
6.4 (Flare Connection)
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
Gas Pipes mm
φ
12.7 (Flare Connection)
φ
15.9 (Flare Connection)
φ
15.9 (Flare Connection)
Drain Pipe mm
VP20
(External Dia. 26 Internal Dia. 20)
VP20
(External Dia. 26 Internal Dia. 20)
VP20
(External Dia. 26 Internal Dia. 20)
Machine Weight kg 24 28 33
★
★★
★
5 Sound Level (H/L) dBA 36/31 39/34 45/37
Safety Devices
Fuse,
Thermal Protector for Fan Motor
Fuse,
Thermal Protector for Fan Motor
Fuse,
Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R410A M Series R410A M Series R410A M Series
Standard Accessories
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Clamps, Washers.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Clamps, Washers.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Clamps, Washers.
Drawing No. 3D035297
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
