Biostar K8M800-M7A [12/71] K8m800 m7a

K8M800-M7A

CNR1: Communication Network Riser Slot

The CNR specification is an open Industry Standard Architecture,

and it defines a hardware scalable riser card interface, which

supports modem only.
