K8M800-M7A BIOS Setup

SYS FAN Speed

This field displays the speed of the SYSTEM fan.

Show H/W Monitor in POST

If you computer contain a monitoring system, it will show PC health status during POST

stage.

The item offers several delay time to select you want

The Choices: Enabled (default), Disabled.

Chassis Open Warning

This item allows you to enable or disable Chassis Open Warning beep.

The Choices: 60

OC/140OF, 65OC/149OF, 70OC/158OF, Dis abl ed (default).
