K8M800-M7A

Note:

Because the overclock, overvoltage, and hardware monitor features

are controlled by several separate chipset, [WarpSpeeder™] divide

these features to separate panels. If one chipset is not on board, the

correlative button in Main panel will be disabled, but will not interfere

other panels’ functions. This property can make [WarpSpeeder™]

utility more robust.

01/03, 2007
