K8M800-M7A BIOS Setup
2
PCI Bus Support
This AWARD BIOS also supports Version 2.1 of the Intel PCI (Peripheral Component
Interconnect) local bus specification.
DRAM Support
DDR SDRAM (Double Data Rate Synchronous DRAM) are supported.
Supported CPUs
This AWARD BIOS supports the AMD CPU.
Using Setup
In general, you use the arrow keys to highlight items, press <Enter> to select, use the
<PgUp> and <PgDn> keys to change entries, press <F1> for help and press <Esc> to quit.
The following table provides more detail about how to navigate in the Setup program by
using the keyboard.
Keystroke Function
Up arr ow Move to pr e vio us it em
Down arro w Move to next item
Left ar ro w Move to th e ite m on th e left (me nu b ar)
Rig ht arrow Move to th e ite m on th e rig ht (me nu bar)
Move Enter Move to the item you desired
Pg Up ke y Increas e t he nu meric val ue or ma ke c ha ng es
Pg Dn ke y Decr ease th e n um eric valu e or ma ke ch ang es
+ Key Increas e t he nu meric val ue or ma ke c ha ng es
- Key Decr ease th e n um eric valu e or ma ke ch ang es
Esc ke y Main Menu – Quit and not s ave c hanges into CMOS
Stat us P ag e S etu p Men u an d Op tion Pag e Set up M en u – E xit
Current pag e a nd r eturn to M ain Menu
F1 key General help on Setup navigation keys
F5 ke y Loa d pr e vious valu es fro m CMOS
F7 ke y Loa d t he opti mize d d efaults
F10 ke y Sa ve all th e CMOS c ha ng es a nd e xit
