K8M800-M7A

1.3 LAYOUT AND COM P ONE NTS

DIMM1

DIMM2

FD D1

K8M800

VT8237R/

VT8237R PLUS

JATXPWR1

JC DI N 1

JUSB2 JUSB3(optional )

JUSB V2

JS AT A2

JS AT A1

JC M O S1

JCI1

JC FAN 1

JSFAN1

Codec

JPANEL1

LAN

PHY

Super I/O

BIO S

BAT1

Socket 754

CPU1

J U SBL A N1

CNR1

PCI1

PCI3

PCI2

AGP1

JK BMS 1

JAUDIO2

JS PD IF_ OU T 1

JATXPWR2

JPRNT1

JUSBV1

JU SB 1

ID E2

ID E1

Note: ■ represents the 1

pin.
