Konica Minolta BizHub 4422 [103/227] Understanding the printer menus 103
![Konica Minolta BizHub 4422 [103/227] Understanding the printer menus 103](/views2/1712903/page103/bg67.png)
Menu item Description
Color
Black and White
Gray
Color*
Auto
Specify the color when scanning an image.
Resolution
75 dpi
150 dpi*
200 dpi
300 dpi
400 dpi
600 dpi
Set the resolution of the scanned image.
Darkness
1–9 (5*)
Adjust the darkness of the scanned image.
Orientation
Portrait*
Landscape
Specify the orientation of text and graphics on the page.
Original Size
[List of paper sizes]
Set the paper size of the original document.
Notes:
• Letter is the U.S. factory default setting. A4 is the international factory
default setting.
• These settings may vary depending on your printer model.
Sides
O*
Long edge
Short edge
Specify the page orientation of text and graphics when scanning a two‑sided
document.
File Name Specify the file name of the scanned image.
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 103
