Konica Minolta BizHub 4422 [62/227] Out of service erase
![Konica Minolta BizHub 4422 [62/227] Out of service erase](/views2/1712903/page62/bg3e.png)
Menu item Description
Scanner Configuration
Scanner Manual Registration
Front ADF Registration
Rear ADF Registration
Flatbed Registration
Manually register the flatbed and ADF after replacing the ADF,
scanner glass, or controller board.
Scanner Configuration
Edge Erase
ADF Edge Erase
0–6 (3*)
Flatbed Edge Erase
0–6 (3*)
Set the size, in millimeters, of the no‑print area around an ADF
or flatbed scan job.
Scanner Configuration
Disable Scanner
Enabled*
Disabled
ADF Disabled
Disable the scanner if it is not working properly.
Scanner Configuration
Scanner Manual Registration
Print Quick Test
Print a test page that shows the scanner margin settings.
Scanner Configuration
Ti
Byte Order
CPU Endianness*
Little Endian
Big Endian
Determine the byte order of a TIFF‑formatted scan output.
Scanner Configuration
Exact Ti Rows Per Strip
On*
O
Set the RowsPerStrip tag value of a TIFF‑formatted scan output.
Note: An asterisk (*) next to a value indicates the factory default setting.
Out of Service Erase
Menu item Description
Out of Service Erase
Memory Last Sanitized
Hard Disk Last Sanitized
Show information on when the printer memory or hard disk was
last sanitized.
Note: Hard Disk Last Sanitized appears only in printers with a
hard disk installed.
Out of Service Erase
Sanitize all information on nonvolatile
memory
Sanitize all information on hard disk
Erase all printer and network settings
Clear all settings and applications that are stored in the printer
memory or hard disk.
Note: Sanitize all information on hard disk appears only in
printers with a hard disk installed.
Understanding the printer menus 62
