Konica Minolta BizHub 4422 [109/227] Understanding the printer menus 109
![Konica Minolta BizHub 4422 [109/227] Understanding the printer menus 109](/views2/1712903/page109/bg6d.png)
Menu item Description
WEP Authentication Mode
Auto*
Open
Shared
Set the type of Wireless Encryption Protocol (WEP) used by the
printer.
Note: This menu item appears only if Wireless Security Mode is set
to WEP.
Set WEP Key Specify a WEP password for secure wireless connection.
WPA2/WPA - Personal
AES
Enable wireless security through Wi-Fi Protected Access (WPA).
Note: This menu item appears only if the Wireless Security Mode is
set to WPA2/WPA-Personal or WPA2-Personal.
Set Pre‑Shared Key Set the password for secure wireless connection.
WPA2 - Personal
AES
Enable wireless security through WPA2.
Note: This menu item appears only if the Wireless Security Mode is
set to WPA2/WPA-Personal or WPA2-Personal.
802.1x Encryption Mode
WPA+
WPA2*
Enable wireless security through 802.1x standard.
Note: This menu item appears only if the Wireless Security Mode is
set to 802.1x - Radius.
IPv4
Enable DHCP
On*
O
Set Static IP Address
IP Address
Netmask
Gateway
Enable and configure IPv4 settings in the printer.
IPv6
Enable IPv6
On*
O
Enable DHCPv6
On
O*
Stateless Address
Autoconfiguration
On*
O
DNS Server Address
Manually Assigned IPv6 Address
Manually Assigned IPv6 Router
Address Prefix
All IPv6 Addresses
All IPv6 Router Addresses
Enable and configure IPv6 settings in the printer.
Network Address
UAA
LAA
View the network addresses.
Understanding the printer menus 109
