Menu item Description
Header/Footer
Top left
Top middle
Top right
Bottom left
Bottom middle
Bottom right
Apply a header or footer on the printed output.
Overlay
Confidential
Copy
Draft
Urgent
Custom
O*
Specify the overlay text printed on each page of the copy job.
Custom overlay Type a custom overlay text.
Note: An asterisk (*) next to a value indicates the factory default setting.
Advanced Imaging
Menu item Description
Color Dropout
None*
Red
Green
Blue
Default Red Threshold
0–255 (128*)
Default Green Threshold
0–255 (128*)
Default Blue Threshold
0–255 (128*)
Specify which color to drop during scanning, and adjust the dropout setting for
that color.
Contrast
Best for Content*
0
1
2
3
4
5
Specify the contrast of the output.
Note: An asterisk (*) next to a value indicates the factory default setting.
