![Konica Minolta BizHub 4422 [115/227] Note this menu appears only in network printers or printers that are attached to print servers](/img/pdf.png)
Konica Minolta BizHub 4422 [115/227] Note this menu appears only in network printers or printers that are attached to print servers
![Konica Minolta BizHub 4422 [115/227] Note this menu appears only in network printers or printers that are attached to print servers](/views2/1712903/page115/bg73.png)
Menu item Description
IKE SA Lifetime (Hours)
1
2
4
8
24*
Set the amount of time before a new authentication key is generated.
Note: These menu items appear only when Base
Configuration
is
set to Secure.
IPSec SA Lifetime (Hours)
1
2
4
8
24*
Proposed Encryption Method
3DES
AES*
Specify the encryption and authentication methods to connect to a
network securely.
Note: These menu items appear only when Base Configuration is
set to Compatibility.
Proposed Authentication Method
SHA1
SHA256*
SHA512
IPSec Device Certificate Specify an IPSec certificate.
Note: This menu item appears only when Base Configuration is set
to Compatibility.
Pre‑Shared Key Authenticated
Connections
Host [x]
Address
Key
Configure the authenticated connections of the printer.
Note: These menu items appear only when Enable IPSec is set to
On.
Certificate Authenticated Connections
Host [x] Address[/subnet]
Address[/subnet]
Note: An asterisk (*) next to a value indicates the factory default setting.
802.1x
Note: This menu appears only in network printers or printers that are attached to print servers.
Menu item Description
Active
O*
On
Let the printer join networks that require authentication before
allowing access.
Note: To configure the settings of this menu item, access the
Embedded Web Server.
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 115
