Menu item Description
PDF Settings
PDF Version
1.3
1.4
1.5*
1.6
1.7
Archival Version
A‑1a*
A‑1b
Highly Compressed
O*
On
Secure
O*
On
Searchable
O*
On
Archival (PDF/A)
O*
On
Set the PDF format of the scanned image.
Content Type
Te xt
Te xt/ P ho to*
Graphics
Improve the output result based on the content of the original document.
Content Source
Black and White Laser*
Color Laser
Inkjet
Photo/Film
Magazine
Newspaper
Press
Other
Improve the output result based on the original document.
Color
Black and White
Gray
Color*
Auto
Specify the color when scanning an image.
Note: An asterisk (*) next to a value indicates the factory default setting.
