Menu item Description
Orientation
Portrait*
Landscape
Specify the orientation of the original document.
Sides
O*
Long Edge
Short Edge
Specify the page orientation of text and graphics when scanning a two‑sided
document.
Content Type
Te xt*
Te xt/ P ho to
Graphics
Improve the output result based on the content of the original document.
Content Source
Black and White Laser
Color Laser*
Inkjet
Photo/Film
Magazine
Newspaper
Press
Other
Improve the output result based on the source of the original document.
Darkness
1–9 (5*)
Adjust the darkness of the scanned image.
Behind a PABX
On
O*
Set the printer to dial a fax number without waiting to recognize the dial tone.
Note: Private Automated Branch Exchange (PABX) is a telephone network that
allows a single access number to oer multiple lines to outside callers.
Dial Mode
To ne*
Pulse
Specify the dial mode for incoming or outgoing faxes.
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 80
