Setting up and using the home screen
applications
Using the home screen
Note: Your home screen may vary depending on your home screen customization settings, administrative
setup, and active embedded solutions.
Touch To
1 Copy Make copies.
2 E‑mail Send e‑mails.
3 Fax Send fax.
4 Status/Supplies
• Show a printer warning or error message whenever the printer requires intervention to
continue processing.
• View more information on the printer warning or message, and on how to clear it.
Note: You can also access this setting by touching the top section of the home screen.
Setting up and using the home screen applications 15
