Remote Operator Panel
Menu item Description
External VNC Connection
Don’t Allow*
Allow
Connect an external Virtual Network Computing (VNC) client
to the remote control panel.
Authentication Type
None*
Standard Authentication
Set the authentication type when accessing the VNC client
server.
VNC Password Specify the password to connect to the VNC client server.
Note: This menu item appears only if Authentication Type is
set to Standard Authentication.
Note: An asterisk (*) next to a value indicates the factory default setting.
Notifications
Menu item Description
Error Lighting
O
On*
Set the indicator light to come on when a printer error occurs.
Note: This menu item appears only in some printer models.
ADF Loaded Beep
O
On*
Enable a sound when loading paper into the ADF.
Alarm Control
O
Single*
Continuous
Set the number of times that the alarm sounds when the printer
requires user intervention.
Supplies
Show Supply Estimates
Show estimates*
Do not show estimates
Show the estimated status of the supplies.
Supplies
Cartridge Alarm
O*
Single
Continuous
Set the number of times that the alarm sounds when the toner
cartridge is low.
E‑mail Alerts Setup Configure the printer to send e‑mail alerts to a list of contacts
when the printer requires user intervention.
Error Prevention
Jam Assist
O
On*
Set the printer to flush automatically blank pages or pages with
partial prints after a jammed page is cleared.
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 56
