91
7
DV MODE PROGRAMMING
Duplex direction setting (DUP)8.
This content appears when “YES” is selected in “R1
USE” as described in ‘Access repeater setting (R1
USE)’ on page 90.
#1 Push [Z](F-2) to display the “DUP” item (Duplex di-
rection setting).
•Theduplexdirectionsettingscreenisdisplayed.
RP–L
DUP :
≈
OFF
ÚÙ
#2 Rotate [MAIN DIAL] to select the duplex direction.
• OFF : The duplex function is OFF.
• DUP– : The transmit frequency shifts down from the re-
ceive frequency by the offset amount.
• DUP+ : The transmit frequency shifts up from the re-
ceive frequency by the offset amount.
Frequency offset programming (OFFSET)9.
This content appears when “YES” is selected in “R1
USE” as described in ‘Access repeater setting (R1
USE)’ on page 90.
#3 Push [Z](F-2) to display the “OFFSET” item (Fre-
quency offset Programming).
•Frequencyoffsetprogrammingscreenisdisplayed.
RP–L
OFFSET:
≈
0.000.0
Ú CLRÙ
#4 Rotate [MAIN DIAL] to select the frequency offset.
•Holddown[CLR](F-3) for1 second to clearthe dis-
played frequency offset.
Storing the repeater list (ADD W10. rite)
#5 Push [Z](F-2) to display the “ADD Write” item (Re-
peater list Storing).
RP–L
ADD Write
Ú WRÙ
#6 Hold down [WR](F-5) to store the entry.
•“ADDWriteOK?”appears.
RP–L
ADD Write OK?
Ú YES NOÙ
#7 Hold down [YES](F-4)tostoretheentry,andreturn
to the RP-L screen.
■ Editing a repeater list
This function re-programs a repeater’s data. This is
useful when already-programmed data is incorrect or
some data should be added to the list.
Repeater list selection1.
q Push [DV•DR] to select the DV mode.
w
P
ush [MENU] one or more times to display the “M3”
screen (Menu 3).
CS CD R>CS UR DSET
M3
e Push [DSET](F-5) to display the “DSET” screen.
DSET
TXM RP
—
L SET
r Push [RP-L](F-4) to display the “RP-L” screen (Re-
peater list).
RP–L
Repeater List
CLR ADD EDT
t
P
ush [EDT](F-5) to display the repeater list.
RP–L
≈
HAMACH43 GRP1
SEL
SEL GRPEDT
y Rotate [MAIN DIAL] to select the desired repeater
to be changed.
RP–L
≈
KOUTOU43 GRP1
SEL
SEL GRPEDT
•Hold down [GRP](F-5) for 1 second to enter the
repeater group selection mode. (“≈” moves next
to the repeater group name, and then blinks.)
Rotate [MAIN DIAL] to select the desired group (0
to 9), then push [GRP](F-5).
Or, you can select the repeater group using the
keypad key.
•“SEL” appears when “R1 USE” setting is set to
“YES.” The selected repeaters can be used as an
access repeater (R1) in the DR mode, and are
scanned during an access repeater scan.
Youcansetthe“SEL”settingbypushing[SEL](F-4).
Repeater data programming2.
u Push [EDT](F-1) to enter the repeater data pro-
gramming mode.
i Push [Y](F-1) or [Z](F-2) to select the item to be
changed.
o Program the selected item data. See pages 89–91
for new repeater list programming details.
RP–L
NAME:
KOUTOU43
Ú EDTÙ
NOTE: If you are reprogramming a repeater with its
own gateway, you must also edit the gateway re-
peater call sign.
■
Repeater list programming (Continued)
