166
14
SET MODE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
EXT-P.AMP (1200) 47. (Default: OFF)
Switch the preamplifier control ON or OFF. When
using the optional AG-1200*, ON must be selected.
Otherwise, the preamplifier will not function.
*AG-1200 has been discontinued, but it can be still be used.
CAUTION: NEVER connect any equipment, such
as an SWR or power meter, between the transceiver
and preamplifier due to the transceiver supplies the
DC voltage to the preamplifier unit when the unit is
ON. Otherwise, the preamplifier may not function
correctly, or the transceiver or external equipment
may be damaged.
This item appears only when the optional UX-9100 is
installed.
EXT-SP Separate 48. (Default: Separate)
Select the audio output method when the optional
external speakers are connected to both [EXT-SP
(MAIN)] and [EXT-SP (SUB)] jacks.
•Separate :The MAIN and SUB Band audio are
separately sent to the [EXT-SP (MAIN)]
and [EXT-SP (SUB)] jacks.
•Mix :The MAIN and SUB Band audio are
combined and sent to both the [EXT-SP
(MAIN)] and [EXT-SP (SUB)] jacks.
Phone Separate 49. (Default: Auto)
Select the audio output method when headphones are
connected to the transceiver.
•Separate :The MAIN and SUB Band audio are
separately sent to the right speaker
(MAIN Band) and left speaker (SUB
Band).
•Mix :The MAIN and SUB Band audio are
combined, and sent to both the right
and left speakers.
•Auto :WhentheSUBBandisdisplayed,the
MAIN and SUB Band audio are sepa-
rately sent to the right speaker (MAIN
Band) and left speaker (SUB Band).
When the SUB Band is not displayed,
the MAIN Band audio is sent to both the
left and right speakers.
Sub Band Mute (TX) 50. (Default: OFF)
Turn the SUB Band Audio Mute function ON or OFF.
While transmitting, the SUB band audio is muted when
this function is turned ON.
•OFF :TheSUBBandaudioisnotmuted
while transmitting.
•ON(SPOnly) :TheSUBBandaudio,senttothe
speaker, is muted while transmit-
ting.
•ON(SP&USB):TheSUBBandaudio,senttothe
speaker and USB port, is muted
while transmitting.
ACC AF/SQL Select 51. (Default: MAIN)
Set the [ACC] socket’s pin 12 (AF) and pin 13 (SQLS)
output usage.
•MAIN:SendstheMAINBand’sreceiveaudioand
squelch.
•SUB :Sends the SUB Band’s receive audioand
squelch.
DATA AF/SQL Select 52. (Default: MAIN)
Set the [DATA2] socket’s pin 4 (DATA), pin 5 (AF) and
pin 6 (SQL) output usage.
•MAIN:SendstheMAINBand’sreceiveaudioand
squelch.
•SUB :Sends the SUB Band’s receive audioand
squelch.
VSEND Select 53. (Default: ON)
Set the [ACC] socket’s pin 7 (VSEND) and pin 3
(HSEND) output usage.
•OFF :VSENDisnotused.
HSEND is used for all bands.
•UHFOnly :VSENDisusedforthe 430MHzand
1200 MHz bands.
HSEND is used for the HF/50 MHz and
144 MHz bands.
•ON :VSEND is used for the 144 MHz,
430 MHz, and 1200 MHz bands.
HSEND is used for the HF/50 MHz
bands.
