Icom IC-9100 [196/212] Control command
![Icom IC-9100 [196/212] Control command](/views2/1074143/page196/bgc4.png)
187
18
CONTROL COMMAND
D Command table (continued)
Cmd.
Sub cmd.
Data Description
1A 05 0054 0000 to
0255
Send/read USB modulation level
(0000=0%to0255=100%)
0055 00 Send/read 9600 bps mode OFF
01 Send/read 9600 bps mode ON
0056 00 Send/read MIC selection for the modula-
tion input during DATA mode OFF
01 Send/read ACC selection for the modula-
tion input during DATA mode OFF
02 Send/read MIC+ACC selection for the
modulation input during DATA mode OFF
03 Send/read USB selection for the modula-
tion input during DATA mode OFF
0057 00 Send/read MIC selection for the modula-
tion input during DATA mode ON
01 Send/read ACC selection for the modula-
tion input during DATA mode ON
02 Send/read MIC+ACC selection for the
modulation input during DATA mode ON
03 Send/read USB selection for the modula-
tion input during DATA mode ON
0058 00 Send/read CI-V transceive OFF
01 Send/read CI-V transceive ON
0059 00 Send/read no function selection for
“USB2” (COM port) function
01 Send/readRTTYselectionfor“USB2”
(COM port) function
02 Send/read DVdat selection for “USB2”
(COM port) function
0060 00 Send/read no function selection for
[DATA1] function
01 Send/readRTTYselectionfor[DATA1]
function
02 Send/read DVdat selection for [DATA1]
function
0061 00 Send/read OFF selection for GPS Out
01 Send/read DATA->USB2 selection for
GPS Out
0062 00 Send/read 4800 bps selection for GPS
position data transmission speed of
[DATA1]
01 Send/read 9600 bps selection for GPS
position data transmission speed of
[DATA1]
0063 00 Send/read300bpsselectionforRTTY
Decode Baud rate
01 Send/read1200bpsselectionforRTTY
Decode Baud rate
02 Send/read4800bpsselectionforRTTY
Decode Baud rate
03 Send/read9600bpsselectionforRTTY
Decode Baud rate
04 Send/read19200bpsselectionforRTTY
Decode Baud rate
0064 00 Send/read Calibration marker OFF
01 Send/read Calibration marker ON
0065 0000 to
0255
Send/read reference frequency
(0000=0%to0255=100%)
0066 00 to 10 Send/read COMP level
(00=Minimumto10=Maximum)
0067 see p. 192 Send/read SSB RX HPF/LPF setting
0068 00 to 10 Send/read SSB RX Tone (Bass) level
(00=–5to10=+5)
0069 00 to 10 Send/read SSB RX Tone (Treble) level
(00=–5to10=+5)
0070 00 to 10 Send/read SSB TX Tone (Bass) level
(00=–5to10=+5)
0071 00 to 10 Send/read SSB TX Tone (Treble) level
(00=–5to10=+5)
0072 see p. 192 Send/read SSB TX bandwidth for WIDE
Cmd.
Sub cmd.
Data Description
1A 05 0073 see p. 192 Send/read SSB TX bandwidth for MID
0074 see p. 192 Send/read SSB TX bandwidth for NAR-
ROW
0075 see p. 192 Send/read AM RX HPF/LPF setting
0076 00 to 10 Send/read AM RX tone (Bass) level
(00=–5to10=+5)
0077 00 to 10 Send/read AM RX Tone (Treble) level
(00=–5to10=+5)
0078 00 to 10 Send/read AM TX tone (Bass) level
(00=–5to10=+5)
0079 00 to 10 Send/read AM TX Tone (Treble) level
(00=–5to10=+5)
0080 see p. 192 Send/read FM RX HPF/LPF setting
0081 00 to 10 Send/read FM RX tone (Bass) level
(00=–5to10=+5)
0082 00 to 10 Send/read FM RX Tone (Treble) level
(00=–5to10=+5)
0083 00 to 10 Send/read FM TX tone (Bass) level
(00=–5to10=+5)
0084 00 to 10 Send/read FM TX Tone (Treble) level
(00=–5to10=+5)
0085 see p. 192 Send/read DV RX HPF/LPF setting
0086 00 to 10 Send/read DV RX tone (Bass) level
(00=–5to10=+5)
0087 00 to 10 Send/read DV RX Tone (Treble) level
(00=–5to10=+5)
0088 00 to 10 Send/read DV TX tone (Bass) level
(00=–5to10=+5)
0089 00 to 10 Send/read DV TX Tone (Treble) level
(00=–5to10=+5)
0090 see p. 192 Send/read CW RX HPF/LPF setting
0091 see p. 192 Send/readRTTYRXHPF/LPFsetting
0092 00 Send/read Normal selection for contest
number style
01 Send/read “190→ ANO” selection for con-
test number style
02 Send/read “190 → ANT” selection for con-
test number style
03 Send/read “90 → NO” selection for con-
test number style
04 Send/read “90 → NT” selection for contest
number style
0093 01 Send/read M1 selection for count up trig-
ger channel
02 Send/read M2 selection for count up trig-
ger channel
03 Send/read M3 selection for count up trig-
ger channel
04 Send/read M4 selection for count up trig-
ger channel
0094 0001 to
9999
Send/read present number
(0001=1to9999=9999)
0095 0000 to
0255
Send/read CW sidetone gain
(0000=0%to0255=100%)
0096 00 Send/read CW sidetone gain limit OFF
01 Send/read CW sidetone gain limit ON
0097 01 to 60 Send/read CW keyer repeat time
(01=1sec.to60=60sec.)
0098 00 Send/read Normal selection for message
display
01 Send/read Message selection for mes-
sage display
0099 28 to 45 Send/read CW keyer dot/dash ratio
(28=1:1:2.8to45=1:1:4.5)
0100 00
Send/read 2 msec. selection for CW Rise time
01
Send/read 4 msec. selection for CW Rise time
02
Send/read 6 msec. selection for CW Rise time
03
Send/read 8 msec. selection for CW Rise time
