SET MODE
External Keypad 54. (Default: OFF)
Turn the external keypad ON or OFF for keyer mem-
ory transmission.
See page 26 for the equivalent circuit of an external
keypad and connection.
•OFF :Theexternalkeypaddoesnotfunc-
tion.
•KEYERSEND:IntheCWmode,pushingoneofex-
ternal keypad switches transmits the
desired keyer memory contents.
USB Audio SQL 55. (Default: OFF(OPEN))
Select whether or not to output the audio from the
[USB] connector on the rear panel, according to the
squelch state.
The same audio signals are sent from the [USB] con-
nector and the [ACC] sockets.
- The beep tones and the voice synthesizer announce-
ments are not sent.
- The received audio output level cannot be adjusted
with the [AF] control.
•OFF(OPEN) :Thereceivedaudioisalwayssent,
regardless of the squelch state.
•ON :Thereceivedaudioissentwhenthe
squelch is open.
USB MOD Level 56. (Default: 50%)
Set the input modulation level of the [USB] connector
tobetween0%and100%in1%steps.
9600bps Mode 57. (Default: OFF)
Turn the [DATA2] socket’s 9600 bps data transmission
ON or OFF.
•OFF:Foronlytheregularaudio(orslowdata)trans-
mission.
•ON :For9600bpsdatatransmission.
DATA OFF MOD 58. (Default: MIC,ACC)
Select the desired connector(s) for data modulation
input in the data OFF mode.
•MIC :Usethesignalsfrom[MIC].
•ACC :Usethesignalsfrom[ACC](pin11).
•MIC,ACC :Usethesignalsfrom[MIC]and[ACC]
(pin 11).
•USB :Usethesignalsfrom[USB].
DATA MOD 59. (Default: ACC)
Select the desired connector(s) for data modulation
input in the data mode.
•MIC :Usethesignalsfrom[MIC].
•ACC :Usethesignalsfrom[ACC](pin11).
•MIC,ACC :Usethesignalsfrom[MIC]and[ACC]
(pin 11).
•USB :Usethesignalsfrom[USB].
CI-V Baud Rate 60. (Default: Auto)
Set the CI-V data transfer rate between 300, 1200,
4800, 9600, 19200 bps and “Auto.”
When “Auto” is selected, the baud rate is automatically
set according to the data rate of the connected con-
troller.
CI-V Address 61. (Default: 7Ch)
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-9100’s address is 7Ch.
When 2 or more IC-9100’s are connected to an op-
tional CT-17
c i -v level converter, rotate [MAIN DIAL] to
selectadifferentaddressforeachIC-9100;therange
is 01h to DFh.
CI-V Transceive 62. (Default: ON)
Turn the transceive function using the CI-V system ON
or OFF.
When this item is set to ON, changing the frequency,
operating mode, etc. on the IC-9100 automatically
changes those settings on other Icom transceivers or
receivers, and vice versa.
•OFF:TransceivefunctionOFF
•ON :TransceivefunctionON
USB2/DATA1 Func 63. (Default: [-----]/GPS)
Two COM port numbers are assigned to the [USB]
connector. One of them is “USB1,” used for cloning
and CI-V operation. The other one is “USB2,” and the
function is selected by this item.
•----- : “USB2” is not used.
•RTTY :UsedtosendRTTYdecodedsignals.
•DVdat :Usedforlow-speeddatainputandoutput.
•Ifyousetthefunctionofthe[DATA1]jackto
“GPS,” and “DATA1 ➔ USB2” is selected as
the “GPS Out” item’s option, as described
below, “USB2” will be used for the low-speed
data input and GPS data output.
