• DV TX call signs setting
Command : 1F 01
Set “UR,” “R1” and “R2” call signs of 8 characters (fixed).
XX
……
XX XXX X XXXX
……
!7–@4o–!6q–i
……
q–i UR (Destination) call sign setting
o–!6 R1 (Access/Area repeater) call sign setting
!7–@4 R2 (Link/Gateway repeater) call sign setting
•Character’scodeofthecallsign
Character ASCII code Character ASCII code
0–9 30–39 A–Z 41–5A
Space 20 ⁄ 2F
• DV TX message setting
Command : 1F 02
Set the transmit message of up to 20 characters.
See ‘Character code setting.’ (p. 190)
“FF” stops sending or reading messages.
• DV RX Status setting
Command : 20 0201, 20 0202
Data
Status Description
Bit
7 0 — —
6 0/1
Receiving a voice
call
During receiving a digital voice
signal, select “1.”
( Regardless of DSQL and
CSQL setting)
5 0/1
Last call finisher When the last call was finished
by you, select “1.”
4 0/1
Receiving a sig-
nal
When the audio tone can be
heard, select “1.”
3 0/1
Receiving a BK
call
During receiving a BK call, se-
lect “1.”
2 0/1
Receiving a EMR
call
During receiving a EMR call,
select “1.”
1 0/1
Receiving a sig-
nal other than DV
When “DV” and “FM” are blink-
ing, select “1.”
0 0/1
Packet loss status During displaying a packet
loss
• DV RX message setting
Command : 20 0101, 20 0102
XX XXXX XX
@1–@8 @9–#2
……
XX
……
XX
q–@0
q–@0RXmessage(20characters;xed)
@1–@8Callsignofthecallingstation(8characters;xed)
@9–#2Noteofthecallingstation(4characters;xed)
See ‘Character code setting.’ (p. 190)
“FF” stands for no message receiving after turning
ON the transceiver.
• DV RX call sign setting
Command : 20 0001, 20 0002
XX XXX XXX XX XX
……
!5–@2e–!0 !1–!4
XXXX
……
q、w
XX
……
XX
@3–#0
XX
……
X X
#1–#8
q Header flag data (First byte)
Data
Description
Bit
7
0
(fixed)
—
6
0
(fixed)
—
5
0
(fixed)
—
4 0/1 0=Voice,1=Data
3 0/1 0=Direct,1=Throughrepeater
2 0/1 0=NoBreak-in,1=Break-in
1 0/1 0=Data,1=Control
0 0/1 0=Normal,1=Emergency
w Header flag data (Second byte)
Data
Function
Bit 2 Bit 1 Bit 0
1 1 1
Repeater control
1 1 0
Send auto acknowledge
1 0 1
(Not used)
1 0 0 Request to re-transmit
0 1 1 Send acknowledge
0 1 0 Receive no reply
0 0 1
Repeater disabled
0 0 0 NULL
e–!0 Call sign of the calling station
(8characters;xed)
!1–!4 Note of the calling station
(4characters;xed)
!5–@2 Call sign of the station that was called
(8characters;xed)
@3–#0 Call sign of the access/area repeater (R1)
(8characters;xed)
#1–#8 Call sign of the link/gateway repeater (R2)
(8characters;xed)
See ‘Character code setting.’ (p. 190)
“FF” stands for no call sign receiving after turning
ON the transceiver.
