RECEIVE AND TRANSMIT
Repeater operation (Continued)
D Setting the Auto Repeater ranges
(U.S.A. and Korea versions only)
The transceiver has three Auto Repeater ranges that
can be used for each frequency band. And you can set
the desired Auto Repeater ranges by programming the
lower and higher edge frequencies into the allowable
Memory channel of each band as described below.
q Select the desired frequency band. (p. 35)
w
Push [AM/FM]
once or twice
to select the FM
mode.
e
S
et the desired lower edge frequency.
r Turn ON the duplex operation, then select the du-
plex direction. (pp. 65, 163)
•“DUP–”or“DUP+”isdisplayedwhentheduplexisON.
•Bothone-touchrepeaterandmanualrepeatersettings
are available.
t Rotate [M-CH] to select a Memory channel of the
selected frequency band.
•SeetheMemorychannelcombinationlisttotheright.
If the HF band is selected in step q, and you want to set
Range 1, select Memory channel 1 for the lower edge
frequency programming.
y Hold down [MW] for 1 second to program the data
into the Memory channel.
•3beepssoundwhenthememory programming is com-
plete.
u Set the upper edge frequency.
i Rotate [M-CH] to select the opposite Memory chan-
nel.
•SelectMemorychannel2ifMemorychannel1isse-
lected in step t.
o Hold down [MW] for 1 second to program the data
into the selected Memory channel.
•3beepssoundwhenthememory programming is com-
plete.
!0 Repeat steps q to o to program other ranges.
NOTE: We recommend that all repeater ranges
are programmed into the Memory channel of
each band. The previously programmed ranges
will be lost.
!1 Hold down [SPEECH/LOCK] for 1 second to turn
ON the Dial Lock function.
•“ ” appears.
!2 Hold down [POWER] for 1 second to turn OFF the
power.
!3 While holding down [AM/FM] and [F-INP ENT],
push [POWER] to turn ON the power.
•“Ω Auto Rptr Set ≈” appears.
•Theprogrammedautorepeaterrangesareset.
•Thememorychannelscanbeusedfornormaloperation
after programming.
!4 Hold down [SPEECH/LOCK] for 1 second to turn
OFF the Dial Lock function.
•“ ” disappears.
• Frequency range and shift direction (Default)
(U.S.A. version)
Band Frequency range (MHz)
Shift direction
50 MHz
51.620000 – 51.999999
52.500000 – 52.999999
53.500000 – 53.999999
“DUP–”
144 MHz
145.200000 – 145.999999
146.610000 – 146.999999
“DUP–”
147.000000 – 147.399999 “DUP+”
430 MHz
442.000000 – 444.999999 “DUP+”
447.000000 – 449.999999 “DUP–”
1200 MHz
1282.000000 – 1295.000000
“DUP–”
(Korea version)
Band Frequency range (MHz)
Shift direction
430 MHz 439.000000 – 440.000000 “DUP–”
1200 MHz
1290.000000 – 1293.000000
“DUP–”
• Memory channel combination of the Auto Re-
peater ranges
(Frequency band: HF/144/430/1200 MHz
)
Lower frequency Higher frequency
Range 1 Memory CH 1 Memory CH 2
Range 2 Memory CH 3 Memory CH 4
Range 3 Memory CH 5 Memory CH 6
(Frequency band: 50 MHz)
Lower frequency Higher frequency
Range 1 Memory CH 7 Memory CH 8
Range 2 Memory CH 9 Memory CH 10
Range 3 Memory CH 11 Memory CH 12
NOTE: Auto Repeater ranges must be programmed
into the Memory channel of EACH band.
[SPEECH/LOCK]
[AM/FM] [BAND](MAIN/SUB)[POWER]
[M-CH]
[F-INP ENT]
[MW]
The optional UX-9100 is required for 1200 MHz frequency
band operation.
