120
8
DV MODE OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Opening Call Sign 17. (Default: OFF)
SelectwhetherornottodisplayMYcallsignonthe
LCD when the transceiver is turned ON.
•OFF : Turns OFF the function.
•ON :DisplaysMYcallsignatpowerON.
BK 18. (Default: OFF)
The break-in function allows you to break into a con-
versation where two other stations are communicating
with call sign squelch enabled.
See page 116 for details.
•OFF :Thebreak-infunctionissettoOFF.
•ON :Thebreak-infunctionissettoON.
•“
” appears on the display.
NOTE: The break-in function is automatically turned
OFF when the transceiver is turned OFF.
EMR 19. (Default: OFF)
The EMR communication mode can be used for digital
mode operation. In the EMR mode, no call sign setting
is necessary. When an EMR mode signal is received,
the audio (voice) will be heard at the specified level
even if the volume setting level is set to minimum level,
or digital call sign/digital code squelch is in use.
See page 115 for details.
•OFF :TheEMRfunctionissettoOFF.
•ON :TheEMRfunctionissettoON.
•“
” appears on the display.
NOTE: The EMR communication function is auto-
matically turned OFF when the transceiver is turned
OFF.
EMR AF Level 20. (Default: 50%)
Enteranumberbetween0%(minimum)and100%
(maximum) to set the audio output level when an EMR
signal is received.
When an EMR signal is received, the audio will be
heard at the programmed level, or the [AF] control
level, whichever is higher.
