9 | Configuration
Installer reference guide
141
ERLA03DAV3 + EHFH03S18DJ3V
Daikin Altherma 3 R F
4P596806-1A – 2020.05
NOTICE
Disinfection mode. Even if you turn OFF domestic hot water operation via the
DHWtank temperature home page (Tank), disinfection mode will remain active.
INFORMATION
Disinfection function is restarted in case the domestic hot water temperature drops
5°C below the disinfection target temperature within the duration time.
INFORMATION
An AH error occurs if you do the following during disinfection:
▪ Set the user permission level to Installer.
▪ Go to the DHWtank temperature home page (Tank).
▪ Press to interrupt the disinfection.
9.4.3 Heat source settings
Backup heater
Backup heater operation mode: defines when backup heater operation is disabled
or only allowed during domestic hot water operation. This setting is only overruled
when backup heating is required during defrost operation or malfunctioning of the
outdoor unit (when [A.6.C] is enabled).
# Code Description
[A.5.1.1] [4‑00] Backup heater operation:
▪ 0: Disabled
▪ 1: Enabled
▪ 2: Only DHW
N/A [5-00] Is backup heater operation allowed above
equilibrium temperature during space heating
operation?
▪ 1: NOT allowed
▪ 0: Allowed
[A.5.1.4] [5‑01] Equilibrium temp.
Outdoor temperature below which operation of
the backup heater is allowed.
Range: –15°C~35°C
INFORMATION
Only for systems with integrated domestic hot water tank: If backup heater
operation during space heating needs to be limited but can be allowed for domestic
hot water operation, then set [4‑00] to 2.
Auto emergency
When the heat pump fails to operate, the gas boiler can serve as an emergency
back-up heater and either automatically or non-automatically take over the entire
heat load.
▪ When auto emergency is set to Automatic and a heat pump failure occurs, the
boiler will automatically take over the heat load.
