13 | Troubleshooting
Installer reference guide
178
ERLA03DAV3 + EHFH03S18DJ3V
Daikin Altherma 3 R F
4P596806-1A – 2020.05
Error code Detailed error code Description
H6 00 OU: Malfunction of position
detection sensor.
Please contact your dealer.
H8 00 OU: Malfunction of
compressor
input (CT) system.
Please contact your dealer.
H9 00 OU: Malfunction of outdoor
air thermistor.
Please contact your dealer.
F3 00 OU: Malfunction of discharge
pipe temperature.
Please contact your dealer.
F6 00 OU: Abnormal high pressure
in cooling.
Please contact your dealer.
FA 00 OU: Abnormal high pressure,
actuation of HPS.
Please contact your dealer.
JA 00 OU: Malfunction of high
pressure sensor.
Please contact your dealer.
J3 00 OU: Malfunction of discharge
pipe thermistor.
Please contact your dealer.
J6 00 OU: Malfunction of heat
exchanger thermistor.
Please contact your dealer.
J6 07 OU: Malfunction of heat
exchanger thermistor.
Please contact your dealer.
L3 00 OU: Electrical box
temperature
rise problem.
Please contact your dealer.
L4 00 OU: Malfunction of inverter
radiating fin temperature
rise.
Please contact your dealer.
