3/7
Breadcrumb Field code Setting name Range, step
Default valu
e
Date Value
Field settings table
Installer setting at variance with
default value
A.2.2.G R/W
0: No
1: Yes
└─ Space operation
└─ LWT settings
└────────────────── Main
A.3.1.1.1 R/W
0: Fixed
1: Weather dep.
2: Fixed / scheduled
3: WD / scheduled
A.3.1.1.2.1 [9-01] Temperature range Minimum temp (heating) R/W 15~37°C, step: 1°C
25°C
A.3.1.1.2.2 [9-00] Temperature range Maximum temp (heating) R/W 37~60°C, step: 1°C
55°C
A.3.1.1.2.3 [9-03] Temperature range Minimum temp (cooling) R/W 5~18°C, step: 1°C
5°C
A.3.1.1.2.4 [9-02] Temperature range Maximum temp (cooling) R/W 18~22°C, step: 1°C
22°C
A.3.1.1.5 [8-05] R/W
0: No
1: Yes
A.3.1.1.7 [2-0C] R/W
0: Underfloor heating
1: Fancoil unit
2: Radiator
└────────────────── Additional
A.3.1.2.1 R/W
0: Fixed
1: Weather dep.
2: Fixed / scheduled
3: WD / scheduled
A.3.1.2.2.1 [9-05] Temperature range Minimum temp (heating) R/W 15~37°C, step: 1°C
25°C
A.3.1.2.2.2 [9-06] Temperature range Maximum temp (heating) R/W 37~60°C, step: 1°C
55°C
A.3.1.2.2.3 [9-07] Temperature range Minimum temp (cooling) R/W 5~18°C, step: 1°C
5°C
A.3.1.2.2.4 [9-08] Temperature range Maximum temp (cooling) R/W 18~22°C, step: 1°C
22°C
└────────────────── Delta T source
A.3.1.3.1 [1-0B] R/W 3~10°C, step: 1°C
5°C
A.3.1.3.2 [1-0D] R/W 3~10°C, step: 1°C
5°C
└─ Room thermostat
A.3.2.1.1 [3-07] Room temp. range Minimum temp (heating) R/W 12~18°C, step: A.3.2.4
12°C
A.3.2.1.2 [3-06] Room temp. range Maximum temp (heating) R/W 18~30°C, step: A.3.2.4
30°C
A.3.2.1.3 [3-09] Room temp. range Minimum temp (cooling) R/W 15~25°C, step: A.3.2.4
15°C
A.3.2.1.4 [3-08] Room temp. range Maximum temp (cooling) R/W 25~35°C, step: A.3.2.4
35°C
A.3.2.2 [2-0A] R/W -5~5°C, step: 0,5°C
0°C
A.3.2.4 R/W
0: 1°C
1: 0,5°C
└─ Operation range
A.3.3.1 [4-02] R/W 14~35°C, step: 1°C
22°C
A.3.3.2 [F-01] R/W 10~35°C, step: 1°C
20°C
└─ Domestic hot water (DHW)
└─ Type
A.4.1 [6-0D] R/W 0: Reheat only
1: Reheat + sched.
2: Scheduled onl
y
└─ Disinfection
A.4.4.1 [2-01] R/W
0: No
1: Yes
A.4.4.2 [2-00] R/W 0: Each day
1: Monday
2: Tuesday
3: Wednesday
4: Thursday
5: Friday
6: Saturday
7: Sunda
y
A.4.4.3 [2-02] R/W 0~23 hour, step: 1 hour
1
A.4.4.4 [2-03] R/W fixed value
60°C
A.4.4.5 [2-04] R/W 40~60 min, step: 5 min
40 min
└─ Maximum setpoint
A.4.5 [6-0E] R/W 40~60°C, step: 1°C
60°C
└─ SP mode
A.4.6 R/W
0: Fixed
1: Weather de
p
.
└─ Weather dependent curve
A.4.7 [0-0B] Weather-dependent curve DHW setpoint for high ambient temp. for DHW
WD curve.
R/W 35~[6-0E]°C, step: 1°C
55°C
A.4.7 [0-0C] Weather-dependent curve DHW setpoint for low ambient temp. for DHW
WD curve.
R/W 45~[6-0E]°C, step: 1°C
60°C
A.4.7 [0-0D] Weather-dependent curve High ambient temp. for DHW WD curve. R/W 10~25°C, step: 1°C
15°C
A.4.7 [0-0E] Weather-dependent curve Low ambient temp. for DHW WD curve. R/W -40~5°C, step: 1°C
-10°C
└─ Heat sources
└─ Backup heater
A.5.1.4 [5-01] R/W -15~35°C, step: 1°C
0°C
A.5.1.5 [8-0E] R/W -15~-7°C, step: 1°C
-7°C
└─ System operation
└─ Auto restart
Modulated LWT
Emitter type
Equilibrium temp.
BUH only ambient temp.
Operation day
Start time
Temperature target
Duration
Room temp. step
Space heating OFF temp
Disinfection
Room temp. offset
Space Cooling ON temp
Delta T cooling
LWT setpoint mode
Delta T heating
LAN Adapter
LWT setpoint mode
(*1) EHFH03S18DJ3V + EKHVCONV3_
(*2) EHFH03S18DJ3V
4P596814-1 - 2019.10
