2/7
Breadcrumb Field code Setting name Range, step
Default valu
e
Date Value
User settings
└─ Preset values
└─ Room temperature
7.4.1.1 R/W [3-07]~[3-06], step: A.3.2.4
22°C
7.4.1.2 R/W [3-07]~[3-06], step: A.3.2.4
18°C
7.4.1.3 R/W [3-09]~[3-08], step: A.3.2.4
24°C
7.4.1.4 R/W [3-09]~[3-08], step: A.3.2.4
28°C
└─ LWT main
7.4.2.1 [8-09] R/W [9-01]~[9-00], step: 1°C
35°C
7.4.2.2 [8-0A] R/W [9-01]~[9-00], step: 1°C
33°C
7.4.2.3 [8-07] R/W [9-03]~[9-02], step: 1°C
18°C
7.4.2.4 [8-08] R/W [9-03]~[9-02], step: 1°C
20°C
└─ Tank temperature
7.4.3.1 [6-0A] R/W 30~[6-0E]°C, step: 1°C
60°C
7.4.3.2 [6-0B] R/W 30~min(50, [6-0E])°C, step: 1°C
50°C
7.4.3.3 [6-0C] R/W 30~min(50, [6-0E])°C, step: 1°C
45°C
└─ Quiet level
7.4.4 R/W
1: Level 1
2: Level 2
3: Level 3
└─ Set weather dependent
└─ Main
└────────────────── Set weather-dependent heating
7.7.1.1 [1-00] Set weather-dependent heating Low ambient temp. for LWT main zone heating
WD curve.
R/W -40~5°C, step: 1°C
-10°C
7.7.1.1 [1-01] Set weather-dependent heating High ambient temp. for LWT main zone heating
WD curve.
R/W 10~25°C, step: 1°C
15°C
7.7.1.1 [1-02] Set weather-dependent heating Leaving water value for low ambient temp. for
LWT main zone heating WD curve.
R/W
[9-01]~[9-00], step: 1°C
35°C
7.7.1.1 [1-03] Set weather-dependent heating Leaving water value for high ambient temp. for
LWT main zone heating WD curve.
R/W [9-01]~min(45, [9-00])°C , step: 1°C
25°C
└────────────────── Set weather-dependent Cooling
7.7.1.2 [1-06] Set weather-dependent Cooling 'Low ambient temp. for LWT main zone cooling
WD curve.
R/W 10~25°C, step: 1°C
20°C
7.7.1.2 [1-07] Set weather-dependent Cooling High ambient temp. for LWT main zone cooling
WD curve.
R/W
25~43°C, step: 1°C
35°C
7.7.1.2 [1-08] Set weather-dependent Cooling 'Leaving water value for low ambient temp. for
LWT main zone cooling WD curve.
R/W [9-03]~[9-02]°C, step: 1°C
22°C
7.7.1.2 [1-09] Set weather-dependent Cooling 'Leaving water value for high ambient temp. for
LWT main zone cooling WD curve.
R/W [9-03]~[9-02]°C, step: 1°C
18°C
└─ Additional
└────────────────── Set weather-dependent heating
7.7.2.1 [0-03] Set weather-dependent heating Low ambient temp. for LWT add zone heating
WD curve.
R/W -40~5°C, step: 1°C
-10°C
7.7.2.1 [0-02] Set weather-dependent heating High ambient temp. for LWT add zone heating
WD curve.
R/W 10~25°C, step: 1°C
15°C
7.7.2.1 [0-01] Set weather-dependent heating Leaving water value for low ambient temp. for
LWT add zone heating WD curve.
R/W [9-05]~[9-06]°C, step: 1°C
50°C
7.7.2.1 [0-00] Set weather-dependent heating Leaving water value for high ambient temp. for
LWT add zone heating WD curve.
R/W [9-05]~min(45,[9-06])°C, step: 1°C
35°C
└────────────────── Set weather-dependent Cooling
7.7.2.2 [0-07] Set weather-dependent Cooling Low ambient temp. for LWT add zone cooling
WD curve.
R/W 10~25°C, step: 1°C
20°C
7.7.2.2 [0-06] Set weather-dependent Cooling High ambient temp. for LWT add zone cooling
WD curve.
R/W 25~43°C, step: 1°C
35°C
7.7.2.2 [0-05] Set weather-dependent Cooling Leaving water value for low ambient temp. for
LWT add zone cooling WD curve.
R/W [9-07]~[9-08]°C, step: 1°C
12°C
7.7.2.2 [0-04] Set weather-dependent Cooling Leaving water value for high ambient temp. for
LWT add zone cooling WD curve.
R/W [9-07]~[9-08]°C, step: 1°C
8°C
Installer settings
└─ System layout
└─ Standard
A.2.1.1 [E-00] R/O
0~5
0: LT s
p
lit
A.2.1.2 [E-01] R/O
0
A.2.1.3 [E-02] R/W (*1)
R/O (*2)
0: Reversible (*1)
1: Heating only (*2)
A.2.1.7 [C-07] R/W
0: LWT control
1: Ext RT control
2: RT control
A.2.1.9 [F-0D] R/W 0: Continuous
1: Sample
2: Re
q
uest
A.2.1.A [E-04] R/O
1: Yes
A.2.1.B R/W 0: At unit
1: In room
└─ Options
A.2.2.1 [E-05] R/O 0~1
1. Yes
A.2.2.3 [E-07] R/O 0~6
1: Integrated
A.2.2.4 [C-05] R/W 0: -
1: 1 contact
2: 2 contacts
A.2.2.A [D-02] R/W
0: No
1: Secondary rtrn
2: Disinf. Shunt
A.2.2.B [C-08] R/W
0: No
1: Outdoor sensor
2: Room sensor
Pump operation mode
User interface location
Which type of DHW pump is installed?
DHW operation
DHW tank type
Thermostat Type
External sensor
Unit type
Compressor type
Indoor software type
Power saving possible
Eco (cooling)
Storage comfort
Storage eco
Reheat
Unit control method
Comfort (heating)
Eco (heating)
Comfort (cooling)
Field settings table
Installer setting at variance with
default value
Comfort (heating)
Eco (heating)
Comfort (cooling)
Eco (cooling)
4P596814-1 - 2019.10
(*1) EHFH03S18DJ3V + EKHVCONV3_
(*2) EHFH03S18DJ3V
