4 | About the units and options
Installer reference guide
20
ERLA03DAV3 + EHFH03S18DJ3V
Daikin Altherma 3 R F
4P596806-1A – 2020.05
4.2.2 Identification label: Indoor unit
Location
Model identification
Example: EHFH03S18DJ3V
Code Description
E European model
HF Floor-standing indoor unit with integrated tank
H H=Heating only
03 Capacity class
S Integrated tank material: Stainless steel
18 Integrated tank volume
DJ Model series
3V Backup heater model
4.3 Combining units and options
INFORMATION
Certain options might not be available in your country.
4.3.1 Possible combinations of indoor unit and outdoor unit
Outdoor unit Indoor unit
EHFH03S18DJ3V
ERLA03DAV3 O
4.3.2 Possible options for the outdoor unit
Bottom plate heater (EKBPHT03D)
▪ Prevents freeze-up of the bottom plate.
▪ Recommended in areas with low ambient temperature and high humidity.
▪ Required in areas with ambient temperatures between –7°C and –15°C when the
outdoor unit is installed between 1000 m and 2000 m altitude. See
"6.1.2 Additional installation site requirements of the outdoor unit in cold
climates"[451] for more information.
▪ For installation instructions, see the installation manual of the bottom plate
heater.
