12 | Maintenance and service

Installer reference guide

168

ERLA03DAV3 + EHFH03S18DJ3V

Daikin Altherma 3 R F

4P596806-1A – 2020.05

8 Remove the water filter.

9 Remove the drain hose from the water filter.

CAUTION

Although the water circuit is drained, some water may be spilled when removing the

magnetic filter/dirt separator from the filter housing. ALWAYS clean up spilled water.

12.5.2 To clean the water filter in case of trouble

1 Remove the water filter from the unit. See "12.5.1 To remove the water

filter"[4167].

CAUTION

To protect the piping connected to the magnetic filter/dirt separator from damage it

is recommended to perform this procedure with the magnetic filter/dirt separator

removed from the unit.

2 Unscrew the bottom of the water filter housing. Use an appropriate tool if

needed.

CAUTION

Opening the magnetic filter/dirt separator is ONLY required in case of severe issues.

Preferably this action is never to be done during the complete lifetime of the

magnetic filter/dirt separator.

a Bottom part to be unscrewed

b Water filter housing

3 Remove the strainer and the rolled‑up filter from the water filter housing and

clean with water.

4 Install the cleaned rolled‑up filter and strainer in the water filter housing.

INFORMATION

Correctly install the strainer in the magnetic filter/dirt separator housing using the

protrusions.
