2-25

ASUS RS100-E10-PI2

10. Connect the SATA signal cable and power cable to the 2.5-inch SSD as shown.

Use the SATA power cable that comes with the SSD drive tray as an add-on accessory.

11. Connect the other end of the SATA signal cable to the SATA connector on the

motherboard.

12. Connect the 4-pin power connector of the power cable to the 4-pin power connector

from the power supply.

Ensure that no cables or connectors are out-of-place.

SSD 1

SSD 2
