Asus ESC8000 G4 [117/192] Legacy console redirection port com1

5-19

ASUS ESC8000 G4 Series

Parity [None]

A parity bit can be sent with the data bits to detect some transmission errors. [Mark]

and [Space] parity do not allow for error detection.

[None] None

[Even] parity bit is 0 if the num of 1’s in the data bits is even

[Odd] parity bit is 0 if num of 1’s in the data bits is odd

[Mark] parity bit is always 1

[Space] parity bit is always 0

Stop Bits [1]

Stop bits indicate the end of a serial data packet. (A start bit indicates the beginning.)

The standard setting is 1 stop bit. Communication with slow devices may require more

than 1 stop bit.

Conguration options: [1] [2]

Flow Control [Hardware RTS/CTS]

Flow control can prevent data loss from buffer overow. When sending data, if the

receiving buffers are full, a “stop” signal can be sent to stop the data ow. Once the

buffers are empty, a “start” signal can be sent to re-start the ow. Hardware ow control

uses two wires to send start/stop signals.

Conguration options: [None] [Hardware RTS/CTS]

VT -UTF8 Combo Key Support [Enabled]

This allows you to enable the VT -UTF8 Combination Key Support for ANSI/VT100

terminals.

Conguration options: [Disabled] [Enabled]

Recorder Mode [Disabled]

With this mode enabled only text will be sent. This is to capture Terminal data.

Conguration options: [Disabled] [Enabled]

Legacy OS Redirection Resolution [80x24]

This allows you to set the number of rows and columns supported on the Legacy OS.

Conguration options: [80x24] [80x25]

Putty Keypad [VT100]

This allows you to select the FunctionKey and Keypad on Putty.

Conguration options: [VT100] [LINUX] [XTERMR6] [SCO] [ESCN] [VT400]

Redirection After BIOS POST [Always Enable]

This setting allows you to specify if Bootloader is selected than Legacy console

redirection.

Conguration options: [Always Enable] [Bootloader]

Legacy Console Redirection Settings

Legacy Console Redirection Port [COM1]

Allows you to select a COM port to display redirection of Legacy OS and Legacy OPROM

Messages.

Conguration options: [COM1] [COM2]
