Appendix

Changing System PCI-E Topology

Changing the system PCI-E topology through the BIOS setup program:

1. Launch the BIOS setup program.

Refer to section

5.2 BIOS setup program

for the steps on launching the BIOS setup

program.

2. Navigate to the

Advanced menu

3. Select

System Topology

and press [Enter], then select

[Single Root]

[Dual Root]

to change your System PCI-E Topology.

2. Navigate to the

Settings

function, then select

System Topology

Changing the system PCI-E topology through the ASMB9-iKVM Web-based user interface:

1. Log in to the ASMB9-iKVM utility.

Refer to the user manual that came with your ASMB9 management card for the steps on

setting up and launching the ASMB9-iKVM Web-based user interface.
