Chapter 2: Hardware Setup
2-10
2.3.2 Memory Configurations
You may install 4GB, 8GB, 12GB, and 32GB RDIMMs; 64GB and 128GB RDIMMs
(3DS); 32GB, 64GB, and 128GB LRDIMMs; 64GB, 128GB, and 256GB LRDIMMs (3DS);
and 128GB, 256GB, and 512GB DCPMMs into the DIMM sockets using the memory
congurations in this section.
• Refer to ASUS Server AVL for the updated list of compatible DIMMs.
• Always install DIMMs with the same CAS latency. For optimum compatibility, it is
recommended that you obtain memory modules from the same vendor.
1 CPU Configuration (must be on CPU1)
DIMM_A2 DIMM_A1 DIMM_B2 DIMM_B1 DIMM_C2 DIMM_C1
1 DIMM
•
2 DIMMs
•
4 DIMMs
• •
6 DIMMs
• • •
8 DIMMs
• • • •
12 DIMMs
• • • • • •
1 CPU Configuration (must be on CPU1)
DIMM_D2 DIMM_D1 DIMM_E2 DIMM_E1 DIMM_F2 DIMM_F1
1 DIMM
2 DIMMs
•
4 DIMMs
• •
6 DIMMs
• • •
8 DIMMs
• • • •
12 DIMMs
• • • • • •
Recommended memory configuration for 1 CPU Configuration
