Asus ESC8000 G4 [163/192] Preferences

ASUS ESC8000 G4 Series

6-17

6.3.4 Preferences

System Preferences

Allow you to set to show the notication area icon and show system information, warning, or

errors here.

E-Mail Preferences

Allow you to set to sent e-mail of the following events:

• Storage system information

• Storage system warnings

• Storage system errors
