5-24
Chapter 5: BIOS Setup
PCI Express Link Register Settings
ASPM Support [Disabled]
Allows to set the ASPM level. Conguration options: [Disabled] [Auot] [Force L0s]
[Force L0s] Force all links to L0s state.
[Auto] BIOS auto congure.
[Disabled] Disabled ASPM.
Unpopulated Links [Keep Link ON]
In order to save power, software will disable unpopulated PCI Express links, if this
option set to Disabled.
Conguration options: [Keep Link ON] [Disabled]
PCIE OPROM Slot Options
PCIE1-3 Slot OPROM [Enabled]
This option allows you to enable or disable the OPROM of the PCIe slots.
Conguration options: [Disabled] [Enabled]
MEZZ1 Slot OPROM [Enabled]
This option allows you to enable or disable the OPROM of the MEZZ slot.
Conguration options: [Disabled] [Enabled]
