13
EN
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
SPECIFIC MANUAL FOR HIGH PRESSURE PUMPS  CH SERIES
WARNING
• ThismanualisdedicatedtoSkilled Techniciansonlyandisnotintendedforusersofthemachineinwhichthepump
isintegrated.FirstofallreadtheGeneralSectionandthenthisSpecicManual.
SPECIFICATIONS AND TECHNICAL DATA
CH 25/500 CH 18/500 CH 22/400 CH 31/300
MECHANICAL CONNECTION
Max power input (kW - HP) 24,0-32,6 17,6-23,9 17,6-23,9 18,4-25,0
Min rotation speed (RPM) 500
Max rotation speed (RPM) 1450 1000 1450
PUMP OIL
(1)
GAZPROM-NEFT SUPER OIL GTD 15W-40
Quantity in weight (kg - lb) 2,21-4,87
Quantity in volume (l - USgal) 2,50-0,66
HYDRAULIC CONNECTION
Max water temperature
(2)
(°C - °F) 40-104
Min water temperature (°C - °F) 5-41
Max water pressure
(3)
(bar - psi) 3-43,5
Min water pressure
(3)
(bar - psi) 0-0
Min water ow rate 1,3 x max ow rate
PERFORMANCE - WEIGHT
Max ow rate (l/min - USgpm) 25-6,6 18-4,7 22-5,8 31-8,2
Max pressure (bar - psi) 500-7250 400-5800 300-4350
Max level of sound pressure - uncertainty 79 dB(A)-1 dB(A)
Weight (kg - lb) 29-64
(1)
Corresponding oils:
MOBIL Delvac MX 15W-40;
SHELL Rimula R4 15W-40;
TOTAL Rubia TIR 7400 15W-40;
ENI i-Sigma performance E7 15W-40.
(2)
Operation at temperatures above 40 °C/104 °F (but in any case within the limit of 60 °C/140 °F) is only possible if the
machine integrating the pump complies with the plant engineering requisites shown in the paragraph “Operation at a
temperature above max value”. In any case, refer to the manual of the machine integrating the pump
(3)
Value to be read at pump suction connection.
Specifications and data are approximate. The Manufacturer reserves the right to make all modifications
to the machine deemed necessary.
STORAGE
CAUTION
• Neverstorethepumpintheopenand,ingeneral,indamppremises.Protectthepumpagainstdirtanddust.
• Forstorageperiodslongerthantwomonths:
- protect the coupling surfaces and the outside machined parts using an anti-oxidising product.
After a very prolonged period of storage (over six months):
• inspectthesuction/deliveryvalves;
• checktheeciencyoftheseals.
EN
