8
English
PRECAUTIONS ON USING CIRCULAR SAW
1. Do not use saw blades which are deformed or
cracked.
2. Do not use saw blades made of high speed steel.
3. Do not use saw blades which do not comply with
the characteristics specified in these instructions.
4. Do not stop the saw blades by lateral pressure
on the disc.
5. Always keep the saw blades sharp.
6. Ensure that the lower guard moves smoothly and
freely.
7. Never use the circular saw with its lower guard
fixed in the open position.
8. Ensure that the retraction mechanism of the guard
system operates correctly.
9. Never operate the circular saw with the saw blade
turned upward or to the side.
10. Ensure that the material is free of foreign matters
such as nails.
11. For model C6SS, the saw blades range should be
from 165 mm to 160 mm.
For model C7SS, the saw blades range should be
from 190 mm to 185 mm.
12. Disconnect the plug from the receptacle before
carrying out any adjustment, servicing or
maintenance.
STANDARD ACCESSORIES
(1) Saw Blade (mounted on tool ) ............................... 1
Dia. 165 mm ............................. C6SS
(
Dia. 190 mm ............................. C7SS
)
(2) Hex. Bar wrench ....................................................... 1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (sold separately)
(1) Dust Collector Set (D)
Connect the suction hose to collect saw dust with
the vacuum cleaner (see Fig. 9).
(2) Washer (A)
............... for 20 mm (Hole dia. of saw blade)
............... for 30 mm (Hole dia. of saw blade)
(3) Guide (with wing-balt)
Optional accessories are subject to change without notice.
APPLICATION
Cutting various types of wood.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position.
If the plug is connected to a receptacle while the
power switch is in the ON position, the power tool
will start operating immediately, which could cause
a serious accident.
3. Extension cord
When the work area is removed from the power
source, use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Prepare a wooden workbench (Fig. 1)
Since the saw blade will extend beyond the lower
surface of the lumber, place the lumber on a
workbench when cutting. If a square block is utilized
as a workbench, select level ground to ensure it
is properly stabilized. An unstable workbench will
result in hazardous operation.
CAUTION
To avoid possible accident, always ensure that the
portion of lumber remaining after cutting is securely
anchored or held in position.
5. How to store the hex. bar wrench (Fig. 8)
The hex. bar wrench used for attaching and
detaching the saw blade can be stored in the handle.
ADJUSTING THE POWER TOOL PRIOR TO USE
1. Adjusting the cutting depth
The cutting depth can be adjusted by moving the
base after loosening its lever (A) (Fig. 2).
CAUTION
Should this lever (A) remain loosened, it will create
a very hazardous situation. Always thoroughly clamp
it.
2. Adjusting the angle of inclination
By loosening the wing bolt at the scale, the saw
blade can be titled up to maximum angle of 45°
against the base (Fig. 3).
The angle of inclination can also be regulated by
loosening the wing bolt at the scale (Fig. 3).
Model C6SS C7SS
Voltage 230 V
Cutting Depth
90° 57 mm 68 mm
45° 38 mm 46 mm
Power Input 1050 W
No-Load Speed 5500 min
–1
Weight (without cord) 3.2 kg 3.4 kg
SPECIFICATIONS
01Eng_C6SS_EE 1/22/09, 14:518
