THE TABLE OF CONTENTS
1. GENERAL OUTLINE .....................................................................14
1.1 Features ............................................................................................ 14
1.2 Unpacking .........................................................................................15
1.3 Model Classication ..........................................................................16
1.4 Basic Specications ..........................................................................17
2. EXPLANATION OF PRINTER PARTS ........................................... 19
2.1 Printer Appearance ...........................................................................19
2.2 Inside the Paper Cover ...................................................................... 21
2.3 Other Built-in Functions .....................................................................23
3. SETUP ............................................................................................ 25
3.1 Connecting the AC Power Cord .........................................................25
3.2 Connecting Cables ............................................................................26
3.3 Bluetooth Interface Board .................................................................. 28
3.4 Bluetooth USB host interface board .................................................. 31
3.5 Ethernet (LAN)/Wireless LAN Interface Board ..................................35
3.6 Lightning USB host interface board ................................................... 39
3.7 Connecting the Cash Drawer ............................................................42
3.8 Precautions for Installing the Printer .................................................44
3.9 Adjusting the Paper Near-end Sensor ...............................................45
3.10 Loading Paper .................................................................................46
3.11 Selecting a Paper Type .................................................................... 48
3.12 Calibrating the Paper Sensor ..........................................................49
3.13 58-mm Width Roll Paper Partition ................................................... 51
3.14 Setting the Long Life Printing (LLP) Function ..................................52
3.15 Mounting the Cable Cover ............................................................... 53
3.16 Precautions for Creating Applications and Practical Operations .....54
3.17 Download Site for Various Electronic Files ...................................... 54
4. MAINTENANCE AND TROUBLESHOOTING ...............................55
4.1 Periodic Cleaning ..............................................................................55
4.2 Clearing a Cutter Error ...................................................................... 56
4.3 Self Test .............................................................................................57
4.4 Hexadecimal Dump Printing .............................................................. 58
4.5 Error Indications ................................................................................59
4.6 Paper Jams .......................................................................................61
4.7 Precautions for Performing Printing for Which
Printing Speed Changes ................................................................... 61
