Citizen CT-E651L [48/72] Selecting a paper type
![Citizen CT-E651L [48/72] Selecting a paper type](/views2/1843441/page48/bg30.png)
48
——
3.11 Selecting a Paper Type
Paper type selection is available by the combination of memory switches MSW4-4
and MSW4-5 by the used of “Memory Switch Select Mode”. In addtion, the following
procedure is available.
1. Enter Selecting Paper Type mode.
1) With the top cover open, turn on the printer power switch while pressing and holding the
FEED key.
The buzzer sounds and the status LED ashes in green.
2) After releasing your nger from the FEED button briey, press the FEED button
consecutively four times.
Next, when the paper is set in place and the top cover closed, the buzzer sounds four short
times and paper selection mode starts.
2. Select Paper Type.
Press the FEED key to match the paper used with the paper type displayed by the status
display LED.
(Refer to the table below.)
Paper roll POWER LED PAPER LED CUTTER LED Buzzer
Thermal roll paper Flashing Unlit Unlit Once
Press the FEED key ↓
Black mark paper Flashing Lit Unlit Twice
Press the FEED key ↓
Label media Flashing Lit Lit Three times
Return to receipt paper selection
3. Save the selected Paper Type to the Printer.
Open the top cover and then close it as it is.
The paper type selected is stored in the printer memory switch as shown in the table below.
The paper type setting mode nishes and the printer restarts automatically.
Paper type
MSW
4-4 4-5
Thermal roll paper Thermal roll paper -
Black mark paper Black mark paper/label media Black mark detection
Label media Black mark paper/label media Label gap detection
