18
——
Item Specications
Operating tempera-
ture and humidity
Thermal roll paper: 5 to 45°C, 10 to 90% RH (no condensation)
Label paper: 5 to 45°C, 10 to 80% RH (no condensation)
Storage temperature
and humidity
-20 to 60°C, 10 to 90% RH (no condensation)
Reliability Thermal roll paper
Print head life: 200 km, 200 million pulses (room temperature, room humidity, specied
recommended paper, specied paper thickness), Auto cutter life: 2 million cuts (3-inch),
1.5 million cuts (2-inch) (room temperature, room humidity, specied recommended
paper, specied paper thickness)
Label media
Print head life: 80 km, 100 million pulses (room temperature, room humidity, specied
recommended paper, specied paper thickness), Auto cutter life: 1 million cuts (2-inch,
3-inch) (room temperature, room humidity, specied recommended paper, specied
paper thickness)
Safety standard *3 UL, C-UL, FCC Class A, CE Marking
Notes:
*1: The number of printable columns is selected using a memory switch.
The numbers of columns noted in this table refer to typical models. The number of
columns varies depending on specications.
*2: Characters appear small because the dimensions include a blank area surrounding
each character.
*3: This standard applies when our AC Adapter (37AD5) is used.
