Citizen CT-E651L [27/72] Caution

——

Use a serial cable with the connection layout shown below.

9-pin (female) - 9-pin (female) cable

PrinterPC

Signal Pin Pin Signal

RXD 2 2 RXD

TXD 3 3 TXD

DTR 4 4 DTR

SG 5 5 SG

DSR 6 6 DSR

RTS 7 7 RTS

CTS 8 8 CTS

CAUTION

Place the interface cable so that people do not trip on it.
