Hikvision DS-1006KI [14/37] Activating your device
![Hikvision DS-1006KI [14/37] Activating your device](/views2/1892089/page14/bge.png)
DS-1200KI/1006KI Keyboard User Manual
DS-6900UDI Decoder User Manual
7
Getting Started Chapter 2
Activating Your Device 2.1
Purpose:
For the first-time access, you need to activate the device by setting an admin password. No
operation is allowed before activation. You can also activate the device via SADP as well.
Step 1 In the Device Activation interface, enter the admin passwords in the text field of Admin
Password and Confirm.
In edit mode, you can press the FOCUS+/A button on the keyboard panel to switch the character
input mode: numerals (123), upper case (ABC) and lower case (abc).
Figure 2-1 Activation Interface
STRONG PASSWORD RECOMMENDED–We highly recommend that you create a strong password
of your own choosing (8 characters, including upper case letters, lower case letters, numbers, and
special characters) in order to increase the security of your product. And we recommend that you
reset your password regularly, especially in the high security system, resetting the password
monthly or weekly can better protect your product.
Step 2 Click Confirm to finish the device activation.
When the device is activated, you need to adjust the date and time settings.
Logging in 2.2
Purpose:
You must log in to the device before configuring the keyboard, and operating the menu and other
functions. Local login and remote login (by Web browser) are optional.
