Figure 4-4 Preset Calling

The preset/patrol/pattern must be pre-configured.

Scene Calling 4.1.3

Purpose:

For the MVC, video wall controller, and decoder added to the keyboard, you can configure the

scene via the iVMS 4200 client first and follow the steps below to switch the scene.

Step 1 In the Keyboard operation mode, press the Num + DEV buttons on the keyboard panel to

select the device ID (decoder, MVC and video wall controller).

Step 2 Press the Num + SCENE buttons on the keyboard panel to switch to the defined scene.

The scene of the video wall must be pre-configured for the decoder or MVC via client software.

Figure 4-5 Scene Calling

AUX Functions 4.1.4

The keyboard is designed with AUX/F2 key on its panel. You are allowed to configure the AUX/F2

key to picture capture or screen jointing functions.

Screen Jointing of Video Wall

Step 1 Log in to the decoder or video wall controller via Web browser, and configure the video wall

settings. Please refer to the user manual of decoder or video wall controller.
