Step 3 Use the joystick to select an operation mode and press OK button to enter the operation.

Keyboard Operation 4.1

The keyboard can be used for managing the devices (including the IPC, IP dome, DVR/NVR, MVC,

decoder, video wall controller, etc.) for control.

Video Wall Control 4.1.1

Purpose:

You can select different window-division display modes for the selected output channel. The

configurable multi-division display modes depend on the decoders, video wall controller, or Multi-

function Video Center (MVC).

The 1/2/4/6/8/9/12/16/25/32/36 window-division display modes are configurable.

Step 1 In the Keyboard operation mode, press the Num + DEV buttons on the keyboard panel to

select the device ID (decoder, MVC and video wall controller).

 When you enter no device ID (DEV), the first decoder (device ID: 1) is set for control by

default. And if you enter no WIN ID, the window 01 is set to play the decoded video by

default.

 The ID for the device (decoder and MVC) and input channel/input channel group can be

viewed on the Device Management>Device List, and Device Management>Input Channel

respectively via Web browser page. Please refer to Chapter 3.3.

Step 2 Press the Num + MON buttons to select the display window for the output channel.

You should use the iVMS-4200 client software to select and drag the output channel to the

corresponding display window on the video wall. Please refer to the user manual of the decoder

or MVC for the details of video wall configuration and operation.

Step 3 Press the Num + MULT buttons to set the window-division display mode for the output

channel.

Step 4 Press the Num + WIN buttons to set the sub-window to play the decoded video. The selected

sub-window ID is shown in [ID] on the interface, e.g., [02].

Dome by

RS-485

The keyboard can connect with the analog dome or PTZ unit

via RS-485 serial port, and realize PTZ control.
