DS-1200KI/1006KI Keyboard  User Manual

DS-6900UDI Decoder User Manual

2) Press the Num + MON buttons to select the display window for the output channel.

3) Press the Num + CAM buttons to select the input channel.

Step 5 Press the AUX/F2 button on the keyboard panel to capture the picture. The picture is saved

in the U-flash disk in FAT32 format.

You can also use the central button of the joystick to capture the picture in keyboard operation

mode.

MAG by IP 4.2

The keyboard can connect with the matrix access gateway, and realize the video wall control, PTZ

control, etc.

Step 1 Log in to the keyboard via Web browser (https://ip address), and enter the Matrix Access

Gateway Settings page.

Figure 4-8 Matrix Access Gateway

Step 2 Configure the parameters of the matrix access gateway. And click OK to save the settings.

Step 3 Enter the MAG by IP operation mode on the keyboard.

Step 4 Press the Num + MON buttons to select the display window for the output channel.

Step 5 Press the Num + WIN buttons to set the window to play the decoded video.

Step 6 Press the Num + CAM buttons to select the input channel group. You can press the

PREV/NEXT buttons to switch to the previous or next camera ID.
