You can also click the Add SADP to add the online devices in the same network segment.

Managing Input/Output Channels 3.2.2

Purpose:

You can manage the import and export of input channels in batch, input group and output

channels via Web browser.

Importing and Exporting Input Channel List

Step 1 Enter the Device Management > Input Channel > Input List page.

Figure 3-4 Import & Export of Input List

Step 2 (optional) You can select an input channel from the list and click Edit to edit the parameters

including the input channel ID, camera name and stream type.

Step 3 Click the Export button to export the input channel list (in excel) to the local directory.

Click the Import button to import the input channel list (in excel) from the local directory.

Managing Input Channel Group

Step 1 Enter the Device Management > Input Channel> Input Group page.

Step 2 Click Add Group to enter the Add Input Group page.

Step 3 Edit the group name, set the auto-switch interval (10-10000 sec) and select the input

channels from the list to the group.
